Model | ZY-2522-W |
|
| Camera |
|
Sensor | 1/1.8" Progressive Scan CMOS |
|
Resolution | 2MP |
|
Low illumination | Color:0.0005 Lux @(F1.5,AGC ON); B/W:0.0001Lux @(F1.5,AGC ON) |
|
S/N ratio | >52dB |
|
D/N mode | Auto ICR, auto, color, B/W |
|
| Lens |
|
Zoom times | f =6.4-160mm ,25X optical,16X digital |
|
Aperture | Max aperture:F1.5~F3.4 |
|
Shutter | 1/25-1/100,000s;support slow shutter |
|
FOV | 62°-3.5°(wide-tele.) |
|
| Encoding |
|
Video encoding | H.265 / H.264,H.265+/H.264+ |
|
H.265 | BaseLine Profile / Main Profile / High Profile |
|
H.264 | BaseLine Profile / Main Profile / High Profile |
|
Video encoding rate | 64Kbps~16Mbps |
|
Audio encoding standard | G.711A/G.711U/G.726/AAC |
|
Audio encoding rate | 16Kbps(G.711)/ ( G.711U )/ (G.726)/(AAC) |
|
| Image |
|
| Main stream | 50Hz: 25fps (1920 × 1080,1280 × 720); 60Hz: 30fps (1920 × 1080,1280 × 720); |
| Second stream | 50Hz: 25fps(720×576,352×288); 60Hz: 30fps(720×576,352×288) |
| Third stream | 50Hz: 25fps(1280 × 720,720×576,352×288); 60Hz: 30fps(1280 × 720,720×576,352×288) |
| Image setting | Brightness, contrast, saturation, sharpness, chroma, adjustable through browser |
| BLC | Support |
| HLC | Support |
| Exposure | Auto Exposure/Manual Exposure/Anti Drag/Low Priority/High Priority/Aperture Priority/Shutter Priority/Lock Mode |
| Focus | Auto focus/manual focus/semi-automatic focus |
| Area focus | Support |
| E-defog | Support |
| Electronic anti-shake | Support |
| D/N shift | Automatic, manual, image algorithm, timing, serial trigger |
| 3D DNR | Support |
| Picture Overlay | Support |
| Permeability | Auto, area setting |
| ROI | 4 areas |
|
| Internet functions |
| Storage | Micro SD/SDHC /SDXC card(256G),NAS(NFS,SMB/CIFS |
| Internet Protocol | TCP/IP,MTU,HTTP,HTTPS,FTP,DHCP,DDNS,UPNP,RTSP,RTMP,NTP,SMTP,PPPOE |
| Protocol | ONVIF/SDK/third-party protocol |
|
|
|
|
|
