Camera |
Sensor | 1/2.9" Progressive Scan CMOS, 3.0 megapixel |
Min. Illumination | Color 0.001 Lux, B/W 0.005,0 Lux with IR, @ ( F1.4,AGC ON ) |
Day/Night | IR-cut filter with auto switch (ICR) |
Shutter | Auto, 1 ~ 1/100000s |
WDR | 120dB |
S/N | >56dB |
Lens type | 18X : 4.7 ~ 84.6mm |
Zoom | Optical 18X |
Iris | F1.6 ~ F3.5 ( 55.3° - 3.2° wide angle – telephoto ) |
HLC | Support |
BLC | Support |
|
Networks |
Protocol | HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181 |
Management User | Support for multi-level user permission management |
|
PTZ Housing |
IR LED Control | 6pcs near IR LED + 3pcs far IR LED |
IR Range | More than 120m IR range |
Warm LED Control | 6pcs near LED + 4pcs far LED |
Warm LED Range | More than 80m IR range |
IR On/Off Control | Auto/Manual |
Horizontal scan | 0°~360°continuously |
Vertical range | -10°~90°(auto flip) |
Horizontal speed | 0.1°~80°/s |
Vertical speed | 0.1°~60°/s |
Max speed | 80°/S |
Preset | 255 |
Patrol scan | 4pcs(16 preset for each) |
R/L Scan | 1 |
Horizontal scan | 1 |
POWER UP ACT | Watch position/L/R Scan/Horizontal 360°scan/Patrol |
Watch position | 1 |
Auto mode | Supports idle actions,power-on actions,and rotation speed can be automatically adjusted based on the lens magnification |
Human-shaped surveillance | Supports human recognition linked with audio-visual alarms and tracking,and allows for freely selecting surveillance areas |
|
General |
Consumption | <40W |
work environment | temperature :-40~60℃;humidity<95% |
Protection level | IP66 waterproof,6000V lightning protection |
Weight | 7.0KG ( Including the package ) |
