TS-501AJ-220BE</br>4″ 2MP 20X Mini IR PTZ Camera -HANGZHOU TSVISION TECHNOLOGY CO.,LTD.

TS-501AJ-220BE 4″ 2MP 20X Mini IR PTZ Camera: Model：TS-501AJ-220BE; Introduction：

▪︎ 1/2.8" Ultra Starlight CMOS Sensor
▪︎ HD-IP 5MP/2K (1980x1080)
▪︎ Optical 20x
▪︎ Smart IR LED, IR Distance > 150M
▪︎ Support POE+++ power supply
▪︎ Support Audio 1 input & 1 output，Alarm 2 input & 1 output
▪︎ All-aluminum alloy structure
▪︎ Free App.: Smart viewer pro

1. High quality image with 2MP,1/2.8" CMOS sensor

2. 1920*1080@30fps in the main stream

3. Ultra 265, H.265, H.264, MJPEG

4. 20X / 33X optical zoom allows for closer viewing of subjects

5. Up to 120 dB Optical WDR (Wide Dynamic Range)

6. Optional DC48V or PoE power supply

7. Audio 1 in and 1 out, Alarm 2 in and 1 out

8. Built-in speaker and micophone

9. 6pcs high-power IR LED, 4pcs laser IR LED, up to 150m (492 ft) IR distance

10. Free viewer pro App.

Camera
Sensor	1/2.8" CMOS Sensor, 2.0 megapixel
Min. Illumination	Color 0.01 Lux, B/W 0.001,0 Lux with IR, Starlight super low illumination
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto, 1 ~ 1/100000s
WDR	120dB
S/N	>56dB
Lens type	4.7 ~ 94mm ( AF automatic focusing and motorized zoom lens )
Zoom	Optical 20X
Iris	20X : F1.6 ~ F2.7

White Balance	Auto / Outdoor
Digital noise reduction	3D DNR
HLC	Support
BLC	Support

Networks
Protocol	TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, STMP
Compatible Integration	ONVIF 2.5

PTZ Housing
IR Range	Up to 150m (492 ft) IR range
Wavelength	850nm
IR On/Off Control	Auto/Manual
Horizontal scan	0°～360°continuously
Vertical range	-10°～90°（auto flip）
Horizontal speed	0.05°～240°/s
Vertical speed	0.05°～100°/s
Max speed	240°/S
Preset	256
Patrol scan	4pcs（10 preset for each）
R/L Scan	1
Horizontal scan	1
POWER UP ACT	Watch position/L/R Scan/Horizontal 360°scan/Patrol
Watch position	1
Optional Alarm in & out	Support
Optional Audio in & out	Support

POE Function
POE supply voltage	DC48V
POE supply PIN	1,2(+).3,6(-) .4,5(+).7,8(-) Auto adaptation
Power	DC12V2A/POE

General
Power	POE injector
Consumption	＜35W
work environment	temperature ：-40～60℃；humidity＜95%
Protection level	IP66 waterproof，6000V lightning protection
Weight	3.5KG
