Sensor

1/1.8" Progressive Scan CMOS, 4K   megapixel

Min. Illumination

Color 0.0005 Lux, B/W 0.0001,0 Lux with IR, @   ( F1.4,AGC ON )

Day/Night

IR-cut filter with auto switch (ICR)

Shutter

Auto, 1 ~ 1/100000s

WDR

120dB

S/N

>56dB

Lens type

40X : 6.4 ~ 256mm, 52X : 6.1 ~ 317mm ( AF   automatic focusing and motorized zoom lens )

Zoom

Optical 40X / 52X, Digital 16X

Iris

40X : F1.4 ~ F4.7 , 52X : F1.5 ~ F4..0


White Balance

Support

Digital noise reduction

3D DNR

HLC

Support

BLC

Support

Optic Defog

Support

Switch mode

Auto, manual, timing, alarm trigger, LDR

Exposure mode

Auto, Manual, Iris-priority ,   Aperture-priority, Shutter-priority

Flip

Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise

Region of interest

ROI support three streams and four fixed   areas

Picture overlay switch

Support BMP 24-bit image overlay,   customizable area

Zoom Camera Interface

Dual Interface

Support HDMI & IP dual output interface

Networks

Protocol

TCP/IP,   UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, STMP,SMTP,IPv6

Compatible Integration

ONVIF (Profile S, Profile G,), API,SDK

PTZ Housing

IR Range

Up to 200m (656 ft) IR range

Wavelength

850nm

IR On/Off Control

Auto/Manual

Horizontal scan

0°～360°continuously

Vertical range

-10°～90°（auto flip）

Horizontal speed

0.05°～240°/s

Vertical speed

0.05°～240°/s

Max speed

240°/S

Preset

256

Patrol scan

4pcs（10 preset for   each）

R/L Scan

1

Horizontal scan

1

POWER UP ACT

Watch position/L/R Scan/Horizontal 360°scan/Patrol

Watch position

1

Optional Alarm in & out

Support

Optional Audio in & out

Support

Optional Wiper

Support

POE Function

POE supply voltage

DC48V

POE supply PIN

1,2(+).3,6(-) .4,5(+).7,8(-) Auto adaptation

Power

DC12V4A/POE

General

Power

POE injector

Consumption

＜35W

work environment

temperature ：-40～60℃；humidity＜95%

Protection level

IP66 waterproof，6000V lightning   protection

Weight

5.0KG
