Camera |
Sensor | 1/2.8" Progressive Scan CMOS, 5.0MP megapixel |
Min. Illumination | Color 0.003 Lux, B/W 0.001,0 Lux with IR, @ ( F1.5,AGC ON ) |
Day/Night | IR-cut filter with auto switch (ICR) |
Shutter | Auto, 1 ~ 1/100000s |
WDR | 120dB |
S/N | >56dB |
Lens type | 22X : 5.2 ~ 114.4mm, 33X : 4.8 ~ 158mm ( AF automatic focusing and motorized zoom lens ) |
Zoom | Optical 22X / 33X, Digital 16X |
Iris | 20X : F1.5 ~ F3.8 , 33X : F1.5 ~ F4..0 |
|
Image |
White Balance | Support |
Digital noise reduction | 3D DNR |
HLC | Support |
BLC | Support |
Optic Defog | Only 33X Support |
Area exposure / focus | Support |
Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Snapshot | Support scheduled snapshots,periodic snapshots,and snapshot at preset positions during patrol |
|
Intelligent |
Smart Fuction | Can simultaneously detect up to 40 faces as targets. Support face detection area masking. Supports three facial capture optimization modes: prioritizing effect, speed, and cycle. Supports detection and capture of boundary crossing, area intrusion, entry into an area, and departure from an area. Supports classification detection and defense of motor vehicles, non-motor vehicles, and pedestrians. Supports classification tracking of motor vehicles, non-motor vehicles, and pedestrians in the scene. |
|
Event |
Basic Detection | Motion detection, Occlusion detection, Sound detection, Alarm input & output |
|
Networks |
Protocol | TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, STMP,SMTP,IPv6 |
Compatible Integration | ONVIF ( Profile G,T,S ), API,SDK,IMOS |
|
PTZ Housing |
IR Range | Up to 150m (492 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Horizontal scan | 0°~360°continuously |
Vertical range | -10°~90°(auto flip) |
Horizontal speed | 0.05°~240°/s |
Vertical speed | 0.05°~240°/s |
Max speed | 240°/S |
Preset | 256 |
Patrol scan | 4pcs(10 preset for each) |
R/L Scan | 1 |
Horizontal scan | 1 |
POWER UP ACT | Watch position/L/R Scan/Horizontal 360°scan/Patrol |
Watch position | 1 |
Optional Alarm in & out | Support |
Optional Audio in & out | Support |
Optional Wiper | Support |
|
POE Function |
POE supply voltage | DC48V |
POE supply PIN | 1,2(+).3,6(-) .4,5(+).7,8(-) Auto adaptation |
Power | DC12V4A/POE |
|
General |
Power | POE injector |
Consumption | <35W |
work environment | temperature :-40~60℃;humidity<95% |
Protection level | IP66 waterproof,6000V lightning protection |
Weight | 5.0KG |
