Sensor

1/2.8" Progressive Scan CMOS, 5.0MP   megapixel

Min. Illumination

Color 0.003 Lux, B/W 0.001,0 Lux with IR, @ (   F1.5,AGC ON )

Day/Night

IR-cut filter with auto switch (ICR)

Shutter

Auto, 1 ~ 1/100000s

WDR

120dB

S/N

>56dB

Lens type

22X : 5.2 ~ 114.4mm, 33X : 4.8 ~ 158mm ( AF   automatic focusing and motorized zoom lens )

Zoom

Optical 22X / 33X, Digital 16X

Iris

20X : F1.5 ~ F3.8 , 33X : F1.5 ~ F4..0


White Balance

Support

Digital noise reduction

3D DNR

HLC

Support

BLC

Support

Optic Defog

Only 33X Support

Area exposure / focus

Support

Flip

Normal/Flip Vertical/Flip   Horizontal/180°/90°Clockwise/90°Anti-clockwise

Snapshot

Support scheduled snapshots,periodic   snapshots,and snapshot at preset positions during patrol

Intelligent

Smart Fuction

Can simultaneously detect up to 40 faces as   targets. Support   face detection area masking. Supports three facial capture optimization modes: prioritizing effect,   speed, and cycle. Supports   detection and capture of boundary crossing, area intrusion, entry into an   area, and departure from an area. Supports classification detection and defense of motor   vehicles, non-motor vehicles, and pedestrians. Supports classification tracking of motor vehicles,   non-motor vehicles, and pedestrians in the scene.

Event

Basic Detection

Motion detection, Occlusion detection, Sound   detection, Alarm input & output

Networks

Protocol

TCP/IP,   UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, STMP,SMTP,IPv6

Compatible Integration

ONVIF ( Profile G,T,S ), API,SDK,IMOS

PTZ Housing

IR Range

Up to 200m (656 ft) IR range

Wavelength

850nm

IR On/Off Control

Auto/Manual

Horizontal scan

0°～360°continuously

Vertical range

-10°～90°（auto flip）

Horizontal speed

0.05°～240°/s

Vertical speed

0.05°～240°/s

Max speed

240°/S

Preset

256

Patrol scan

4pcs（10 preset for   each）

R/L Scan

1

Horizontal scan

1

POWER UP ACT

Watch position/L/R Scan/Horizontal 360°scan/Patrol

Watch position

1

Optional Alarm in & out

Support

Optional Audio in & out

Support

Optional Wiper

Support

POE Function

POE supply voltage

DC48V

POE supply PIN

1,2(+).3,6(-) .4,5(+).7,8(-) Auto adaptation

Power

DC12V4A/POE

General

Power

POE injector

Consumption

＜35W

work environment

temperature ：-40～60℃；humidity＜95%

Protection level

IP66 waterproof，6000V lightning   protection

Weight

5.2KG
