Camera |
Sensor | 1/1.8" Progressive Scan CMOS, 4K megapixel |
Min. Illumination | Color 0.0005 Lux, B/W 0.0001,0 Lux with IR, @ ( F1.4,AGC ON ) |
Day/Night | IR-cut filter with auto switch (ICR) |
Shutter | Auto, 1 ~ 1/100000s |
WDR | 120dB |
S/N | >56dB |
Lens type | 40X : 6.4 ~ 256mm, 52X : 6.1 ~ 317mm ( AF automatic focusing and motorized zoom lens ) |
Zoom | Optical 40X / 52X, Digital 16X |
Iris | 40X : F1.4 ~ F4.7 , 52X : F1.5 ~ F4..0 |
|
Image |
White Balance | Support |
Digital noise reduction | 3D DNR |
HLC | Support |
BLC | Support |
Optic Defog | Support |
Switch mode | Auto, manual, timing, alarm trigger, LDR |
Exposure mode | Auto, Manual, Iris-priority , Aperture-priority, Shutter-priority |
Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Region of interest | ROI support three streams and four fixed areas |
Picture overlay switch | Support BMP 24-bit image overlay, customizable area |
|
Zoom Camera Interface |
Dual Interface | Support HDMI & IP dual output interface |
|
Networks |
Protocol | TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPOE, UPNP, STMP,SMTP,IPv6 |
Compatible Integration | ONVIF (Profile S, Profile G,), API,SDK |
|
PTZ Housing |
IR Range | Up to 150m ( 492 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Horizontal scan | 0°~360°continuously |
Vertical range | -10°~90°(auto flip) |
Horizontal speed | 0.05°~240°/s |
Vertical speed | 0.05°~240°/s |
Max speed | 240°/S |
Preset | 256 |
Patrol scan | 4pcs(10 preset for each) |
R/L Scan | 1 |
Horizontal scan | 1 |
POWER UP ACT | Watch position/L/R Scan/Horizontal 360°scan/Patrol |
Watch position | 1 |
Optional Alarm in & out | Support |
Optional Audio in & out | Support |
Optional Wiper | Support |
|
POE Function |
POE supply voltage | DC48V |
POE supply PIN | 1,2(+).3,6(-) .4,5(+).7,8(-) Auto adaptation |
Power | DC12V4A/POE |
|
General |
Power | POE injector |
Consumption | <35W |
work environment | temperature :-40~60℃;humidity<95% |
Protection level | IP66 waterproof,6000V lightning protection |
Weight | 5.0KG |
